Labtech LT-100
Hematology Analyzer > Labtech LT-100
LT-100
Technical Specifications
- user friendly software
- End point method- Storage of abs of regent blank in memory/10 graphs for KIN test
- Triplicate calibration mode for EP/KIN/Fix time.
- Triplicate mode of sampling with / SD / CV
- print out of laboratory and doctor’s name
- for kinetic test : Online graph and OD, Graph editing facility, estimation of result
- Air purge between sample to avoid carry over / lamp saver made
- 35 Direct Test keys for test selection
- Utility mode for self diagnosis checking / 16 bit ADC
- Sample type : serum/ plasma / CSF / urine / whole blood / hemolysate
- Calculator for lipid profile globulin ration/ S. Iron TIBC / Billirubin
Product Description
Additional Information
Product Description
Method of Calculations
- Absorbance
- End Point
- Fixed time : with standard or factor
- Kinetics
- Differential/Coagulation – PT/APPT/ Multipoint upto 10 standards
Optical system
- Principle : Aborption spectrophotometry
- Measurement : From – 0.1 to 3.0 a for
- Spectral range : Automatic via filter wheel
- Filters : 340, 405, 505, 546, 578 & 630 nm (450&670)*
- Bandwidth : 8nm(+2nm)
- Light source : Halogen lamp 12v/20W or 6v / 10W
- Zero : Automatic
- Settings : Monochromatic and Bi-chromatic mode
- Detector : Schottkey type photodiode – silicon
Thermostat : Flowcell/cuvette chamber
- Accuracy : + 0.10C
- Peltier regulated from 200C in steps of 1 C
Cuvettes
- Flow cell of 18 uL or 32 uL
- Cuvettes : Semi-micro plastic or glass
Suction System
- Bi-Directional peristaltic pump/Sipping
- volume programmable from 100 uL to 1.0ml.
Additional Information
Interface
- Screen : Graphic LCD 240/128 pixels
- Keyboards : Tactile Soft – Touch/USB*
- Printer : Built-in 57mm thermal printer RS – 232 for pc connection
- Parallel port for 80 column dot matrix printer*
Dry Bath Incubator
- 13mm diameter : 15 positions
- 10mm diameter : 4 positions
- Default Temperature : 370C+0.20C
- 3 inbuilt Timers : T1/T2/T3
Power/ Dimensions
- Voltage : 110-220V / 50-60 Hz
- Power Supply : <110W
- Temperature : 100C to 400C Relative humidity < 80%
- Dimensions : 13mm diameter
Programming
- Table of tests : up to 235
- Table of units : up to 9 units (editable)
- Memory : 1000 test results
Quality Control
- 3 controls per test – Low, Normal & high
- Quality control storage
- Levy-Jennings charts & Westagard’s rules
